Leica S-E (Typ 006)
This is a demonstration store. You can purchase products like this from Leica Store Miami.
-
With the new Leica S-E. Leica Camera AG. Wetzlar. offers an ideal entry-level model for Leica S medium-format system. The camera provides practically all technical advantages of the Leica S (Type 006) and presents an attractive alternative within the Leica S-System. The new colour scheme. with a top deck in anthracite grey paint and a silver anodised shutter speed dial. adds even more to its attraction.
The S-E (Type 006) offers photographers access to the entire portfolio of lenses. technical equipment and accessories available for the Leica S-System. Owners of a Leica S-E can also enjoy the benefits of S-System service and extend the warranty for the camera body to three years with the optional Leica Protection Plan.
Read More...Proven advantages of the S-System
The Leica S-E possesses all proven quality characteristics of the S-System. These include the large 30 × 45 mm Leica Pro Format sensor and its micro-lens layer that guarantees consistently uniform brightness from corner to corner. The camera is extremely ruggedly built and sealed against environmental influences like dust and rain – just like all S-Lenses. The system's unique dual-shutter concept offers photographers the choice of using the camera's fast focal plane shutter with speeds up to 1/4000 s or the electronically controlled central shutter of the CS lenses that allows flash sync at shutter speeds up to 1/1000 s. The ten currently available Leica S-System lenses (six of which are also available with a central shutter) offer photographers all important focal lengths and a first-class tilt/shift lens. The latest member of the family to be launched by Leica is the Summicron-S 100 mm f/2 ASPH.. a lens particularly suitable for portrait photography. At the same time. numerous third-party medium-format lenses can be mounted on the Leica S-E by means of Accessories_Adapters. For instance. the Leica S-Adapter C allows the use of Contax 645 lenses and the Leica S-Adapter H provides full compatibility for all functions of Hasselblad H lenses. including auto-focus. central shutter control and automatic aperture control.
Further details. like secure cable connections. optimized energy efficiency or the scratch-resistant display. ensure that photographers never compromise when they choose a Leica S-E. The Leica S-E therefore stands as an ideal and extremely reliable tool for achieving the best possible results in the studio and on location – under even the most unfavorable conditions.
Camera type: Digital medium-format single lens reflex camera for use with Leica S-Lenses. Image sensor Type: Leica CCD sensor with micro-lens layer Size: 30 × 45 mm (Leica Pro Format) Aspect ratio: 2:3 Resolution: 37.5 megapixels Pixel pitch: 6 µm Dynamic range: 13 stops Color depth: 16 bits per pixel Color spaces: sRGB. Adobe RGB. ECI RGB 2.0. White balance: Presets: daylight. cloudy. shade. incandescent. HMI. fluorescent warm. fluorescent cool. flash. grey card (determined from image). grey card Live View. automatic. color temperature (kelvin) Low-pass filter / IR filter: No / on sensor Moiré suppression: In external image-processing software (e.g. with the Adobe Lightroom® software provided with the camera) Lens mount: Leica S-Bayonet for Leica S-Lenses Focal length: Dependent on Leica S-Lens attached. conversion factor to 35 mm film equivalent 0.8× Focusing Type: Predictive AF with center cross-sensor defined by cross-hairs on the Accessories_Focusing Screen. focusing drive integrated in lenses AF modes: AFs (single) = focus priority. AFc (continuous) = predictive focus tracking. MF (manual). manual override possible at any time
AF memory: Second resistance point hold on shutter release. lock for single exposure or constant by setting with five-way switch
Manual focus: With lens focusing ring Exposure metering: Exposure metering through the lens (TTL) Metering modes: Multi-segment metering (five fields). centre-weighted integral metering. selective (spot) metering (3.5% of image frame) AE lock:
Second resistance point hold on shutter release. lock for single exposure or constant by setting with five-way switch
Metering range: (at f/2.5 and ISO 100) Spot metering: EV 2.7 - 20. center-weighted and multi-segment metering: EV 1.2 - 20 Exposure control: Program AE (with shift function) (P). shutter priority AE (T). aperture priority AE (A). manual metering (M) Exposure compensation: ± 3 EV in half-EV increments Bracketing (AEB): Three/five exposures (automatic/manual). half. one. two or three stops
ISO sensitivity: ISO 100. ISO 200. ISO 400. ISO 800. ISO 1600. auto ISO
Shutter Type: In-camera: Microprocessor-controlled. metal-blade. vertical focal-plane shutter Shutter speeds: Manual setting (T and M modes): 6 s to 1/4000 s in half-stop increments. time exposure (B mode): up to max. 125 s. flash sync speed 1/125 s. automatic (A and P modes): continuous from 32 s to 1/4000 s
CS shutter option: Optional central shutter in Leica S-Lenses (CS versions) CS shutter speeds: Manual setting (T and M modes): 6 s to 1/1000 s in half-stop increments. flash sync at all speeds. automatic (A and P modes): continuous from 8 s to 1/1000 s
Linear flash mode: Faster sync speeds than 1/125 s possible with Leica SF 58 flash unit and HSS-capable SCA 3002 flashes Continuous shooting: ~ 1.5 fps Shutter release: Three stages Self-timer: Two- or 12-second delay Mirror pre-release: Yes Viewfinder
Type:High-eye-point pentaprism Magnification: 0.87× (with 70 mm lens at infinity) Viewfinder coverage: Approx. 98% Dioptre compensation: –3 to +1 dioptres Focusing screen: Interchangeable Top-deck display: Full-colour. self-illuminating. top-deck panel (OLED) Monitor: 3 TFT LCD monitor with 921.600 pixels. 16 million colours. sRGB colour space. image field approx. 100%. maximum oblique viewing angle 170°
Protective cover: Anti-glare dirt-repellent protective glass cover in scratch-resistant Corning Gorilla Glass® Flash
Mount:Hot shoe with centre and control contacts. LEMO® flash connection socket Compatibility: Full compatibility with Leica SF58 and flash units with SCA3002 Accessories_Adapters X synchronisation: 1/125 s. 1/1000 s (lens CS). sync at all slower speeds. choice of first or second curtain sync; FPS flash sync at faster shutter speeds (1/180 s to 1/4000 s) possible with suitably equipped flash units (HSS mode)
Flash reflector angle:
Automatic adaptation to focal length of lens attached with Leica SF58 flash unit or system-compatible flash units with motorised zoom reflector Exposure
Exposure modes:Single frame. continuous. self-timer 2 s (with mirror pre-release). self-timer 12 s (with mirror pre-release) Data recording
Image file formats:DNG (5000 × 7500 pixels. 37.5 megapixels. approx. 72 MB per image). lossless compressed DNG (7500 × 5000 pixels. approx. 42 MB per image). JPEG (7500 × 5000 pixels. in three resolutions. 37.5. 9.3. 2.3 megapixels. approx. 1–16 MB per image. depending on resolution and image content) Maximum burst rate: 1.5 fps Buffer memory: DNG max. 28 images. DNG compressed max. 32 images. JPEG no limit Simultaneous capture option
for DNG and JPG:Yes Storage media: SD card (SD cards to 2 GB max.. SDHC card to 32 GB max.. SDXC card). CompactFlash card (UDMA7). external transfer to PC hard disk
Other functions
Menu languages:English. German. French. Italian. Spanish. Russian. Japanese. traditional Chinese. simplified Chinese. Portuguese. Korean Firmware update: User upload option GPS: Selectable (may not be available in all countries due to local legislation) Date/time: User setting option. automatic date. time and time zone synchronisation with activated GPS module Levellingy: Determination by acceleration sensor. accuracy and display sensitivity <1° at 0–40°C (32–104°F) ambient temperature Interfaces
USB:ISO hot shoe. LEMO® USB 2.0 HiSpeed HDMI type C socket. remote release. X-flash sync. SCA3002. LEMO® flash connection socket. interface for Leica multifunctional handgrip S Supported operating
systems:Windows XP®. Windows Vista®. Windows 7®. Apple Macintosh Mac OS X® 10.5 and higher
Software
Software package:Adobe Photoshop Lightroom® and Leica Image Shuttle 2. downloadable from the Leica owners' area after product registration Power supply
Battery:Rechargeable lithium-ion battery. nominal voltage 7.4 V. capacity 2100 mAh
Battery-independent
power supply:With Leica AC adapter S (optional accessory) Power supply and
battery charger:Rapid charger S (with integrated US mains plug. plugs for EU. UK and Australia and car adapte Inputs: 100–240 V AC. 50/60 Hz. automatic toggle. or 12/24 V DC; output: 7.4 V DC. 1250 mA
Body
Body construction:Full-metal chassis in die-cast magnesium alloy with high-grip plastic coating. anthracite grey magnesium alloy top deck. baseplate in fibreglass-reinforced polycarbonate
Operating conditions:
0 to +45°C (32 to 113°F). 15–80% relative humidity Dimensions (W × H × D):
160 × 80 × 120 mm Weight:
Approx. 1260 g (body only. with battery)
Dust-proof/splash-proof:
Yes/yes Tripod bushes:
1/4 and 3/8 with anti-twist locking pins Package
Package contents:
S body. rapid charger S (with integrated US mains plug. interchangeable plugs for EU. UK and Australia and car adapter). rechargeable lithium-ion battery. carrying strap. bayonet body cap. eyepiece cap
